The GL601.K433.0075V-Coupling Screw Centrifugal Pump represents far more than just a standard fluid transfer device; it is a highly efficient, stable, and intelligent fluid processing ecosystem designed to directly empower your operational cost reduction and efficiency improvement goals. Built with a robust horizontal wet-type structure, you can immediately sense the durability in its heavy-duty metallic casing, engineered to withstand continuous industrial use without structural fatigue. At its core, this spiral centrifugal pump adopts a powerful 7.5KW variable frequency motor that fundamentally redefines energy conservation. Instead of relying on the highly inefficient and mechanically stressful habit of valve throttling, the motor speed is continuously and dynamically adjusted by the frequency converter. This precise calibration provides real-time flow and head exactly according to your system's demand. The result is a quiet, vibration-free operation where the comprehensive energy-saving rate can reach up to an impressive 30% - 50%.
Intelligent Automation & Control: Designed for modern facility architectures, this unit offers easy and seamless integration with existing PLC/DCS networks. This allows operators to achieve fully automatic and precise control of liquid level, pressure, and flow, drastically reducing manual intervention on the factory floor and improving the overall automation level of your fluid management system.
Premium Sealing & Soft Start/Stop Protection: Equipped with a high-quality double mechanical seal, the pump effectively prevents hazardous medium leakage and protects internal components. Furthermore, the advanced soft start/stop function ensures the starting current remains strictly less than the rated current. This guarantees no sudden electrical impact on the power grid and completely eliminates the destructive physical shock of "water hammer" damage to pumps and pipeline systems, significantly extending equipment life.
Unmatched Non-Clogging Core Structure: Featuring a unique spiral centrifugal impeller design, this pump excels at the non-destructive, completely non-clogging transportation of high-concentration liquids, large solid particles, and long-fiber media. It glides through challenging materials smoothly, eliminating the harsh grinding noises typical of standard impellers struggling with debris.
Exceptional Capability & Material Customization: Operating with a maximum head of 30 meters and a maximum speed of 2900r/min, it functions as a highly capable, relatively small spiral centrifugal pump. To combat severe corrosive and abrasive industrial environments, the water-wading material can be fully customized according to the on-site environment (including premium 304/316L stainless steel, etc.), ensuring long-term structural integrity.
Application scenario: Born specifically to resolve chronic industry pain points, this screw centrifugal pump thrives in environments where standard equipment routinely fails. Whether you are dealing with thick, odorous sludge, abrasive mineral mixtures, or highly acidic chemical fluids, the GL601.K433.0075V model maintains a consistent, reliable flow. Its unique internal geometry allows fragile solids to pass through entirely intact, while tough, stringy materials are directed safely through the chamber, preventing entanglement and unexpected operational downtime.
Wastewater Treatment Industry: Serves as the ideal choice for demanding water inlet lifting, heavy sludge return, and dense residual sludge discharge. Its proven non-clogging characteristics make it the perfect, maintenance-friendly partner operating reliably behind the grille.
Municipal and Building Drainage: When it comes to improving large-scale rainwater management and clearing unpredictable, debris-filled basement water, this equipment is absolutely irreplaceable in terms of steadfast reliability during critical weather events.
Paper and Pulp Industry: Delivers highly efficient transportation of various types of thick virgin pulp and recycled waste paper pulp, operating continuously without any fear of debilitating fiber entanglement that typically halts production lines.
Food and Beverage Industry: Expertly transports viscous sauces, dense fruit and vegetable residues, and active fermentation liquids containing solid particles. It perfectly balances strict facility hygiene requirements with gentle, non-destructive handling of sensitive organic materials.
Chemical and Mining Industries: Built to endure the harshest processing conditions, it handles the transportation of highly corrosive slurries containing sharp crystals and abrasive particles with remarkably stable and reliable performance.
We deeply understand that an excellent pump set is the beating lifeblood of your continuous production process. A single point of failure can disrupt an entire facility's output. Therefore, we offer a comprehensive ecosystem of support to ensure flawless integration and sustained performance:
Professional Selection & Adaptation: Our experienced engineers provide the optimal model selection based precisely on your specific medium and working conditions. This includes seamless pipeline adaptation for an outlet diameter ranging from 80-150mm, ensuring a perfect physical fit for your existing infrastructure.
Rigorous Quality Manufacturing & Testing: Using premium-grade materials (such as heavy-duty cast iron, customized stainless steel, etc.) and precision machining, we strictly execute industrial-grade factory testing. This guarantees the factory quality and extreme-environment readiness of each individual pump unit before it ever reaches your facility.
Comprehensive Service Support: From initial installation guidance and complex system debugging to long-term after-sales maintenance and responsive online service, we provide professional technical support throughout the entire process, making us your most reliable operational partner.
Product Name | High head screw centrifugal pump |
Model (Serial Number) | GL601.K433.0075V |
Structure | Horizontal, wet type |
Sealing Method | double mechanical seal |
Maximum Flow (m^3/h) | 50 |
Maximum Head (m) | 30 |
Voltage (V) | 380 |
Frequency (HZ) | 50 |
Outlet Diameter (mm) | 80-150（Can be equipped with adapters according to needs） |
Temperature of the Conveying Medium (℃) | 0-70 |
Cooling Method | dry environment |
Customized | Variable frequency motor |
After-sale Service | online service |
